Philips 65BDL3052E/00 LCD Large Format Display Monitor

£1443 (£1731.60 inc. VAT)
Availability: Please Call

Philips 65BDL3052E/00 Suggested Applications

Key Features

  • 65" Diagonal ADS Panel
  • 65" Powered by Android, Multi-touch
  • VESA 400×400mm; M8 mounting points
  • USB Media Player - Play JPeG images, MP3 audio or MPG video from a USB memory stick
  • OPS Slot - Allows expansion modules such as PC boards, HD-SDI interfaces to be added
  • LAN Control/Monitoring - The monitor can be controlled through your local area network
  • SD Card Slot - For media transfer
  • Designed for 18/7 use - Warranty covers use up to 18 hours per day

Powered By Android

WIth Android OS integrated into the display, you can work with the most developed OS on the planet and save your own app directly into the display. Or, choose from the large library of Android apps and play content from there. With the built-in scheduler, you can daypart your apps and content based on your customer and time of day and with the auto orientation feature, showing content in portrait or landscape is as simple as turning the display.

CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

Multi-touch technology

Create a memorable interactive experience with up to 20 touchpoints at the same time. Perfect for collaborative and competitive applications, this display connects your audience with any content - making it ideal for education, public venues, corporate, hospitality, and retail settings. The touch panel is HID compliant, providing true plug-and-play operation.

OPS slot

Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.

Whiteboard mode built-in

Inspire agile collaboration with whiteboard mode. Simply activate this feature to turn your display into a blank canvas that can be drawn on by multiple users by hand or with dedicated display markers. Everything on screen can then be captured for easy printing or file sharing.

Philips 65BDL3052E/00 Downloads

Philips 65BDL3052E/00 Summary

Model Philips 65BDL3052E/00
EAN / UPC 8712581785284
Display Type ADS
Features USB Media Player
OPS Slot
LAN Control/Monitoring
SD Card Slot
Designed for 18/7 use
Diagonal 65"
Native Resolution 3840×2160
Brightness 350cd/m2
Contrast 1,200:1
Pixel Pitch 0.372 ×0.372 [mm]mm
Colours 1.07 B

Connectivity

VGA / 15pin d-sub 1
DVI 1
HDMI 3
USB-C Video 1
Audio in 1
USB 4
RS-232 1

General Specifications

Speakers 2×15 W
Warranty 5-year warranty
Monitor Dimensions 149.4 × 88.3 × 10cm (w×h×d)
Weight 43.5kg.
VESA 400×400mm; M8
Power Supply 100 ~ 240 VAC, 50/60 Hz
Consumption 155w

Display

Viewing angle 178° Horizontal
178° Vertical
Picture enhancement 3:2 - 2:2 motion pull down; 3D Comb filter; Motion compensation deinterlacing; Progressive scan; 3D MA deinterlacing; Dynamic contrast enhancement
Screen-saving functions Pixel Shift, Low Brightness
Protection glass Anti-Glare; Tempered safety glass 7 MOHS

Control

External control IR (in/out) 3.5 mm jack; RJ45; RS232C (in/out) 2.5 mm jack
Other connections OPS; micro SD; USB-B (x 3)
Signal loop through RS232; IR Loop through
Network controllable RS232; RJ45
Keyboard control Lockable
Remote control signal Lockable

Mechanical

Bezel width 17.8 mm(T/R/L)×31.7 mm(B)
Temperature range 0 ~ 40° Operation
-20~60° Storage
Altitude 0 ~ 3000 m
MTBF 50,000 Hours
Humidity range 20–80% operation, without condensation
5–95% storage, without condensation
Consumption (Max) 376 W
Standby power consumption <0.5 W
Power Saving Features Smart Power
Energy Label Class G

Media Playback

Operating system Android 8.0
USB Playback Video H.263; H.264; H.265; MPEG1/2; MPEG4; VP9
USB Playback Picture BMP; JPEG; PNG
USB Playback Audio AAC; MPEG; HEAAC
Multi-touch technology 0-gap Infrared touch
Touchpoints 20 simultaneous touch points
Plug and play HID compliant

Media Playback

CPU 2×A53 + 2×A73
GPU ARM Mali G51
Memory 3 GB DDR3
Storage 16 GB EMMC
Smart Insert mount 100×100 mm, 6xM4L6

Other Features

Ease of installation AC Out; Smart Insert
Other convenience Carrying handles
Optional accessories Interact dongles
On-Screen Display Languages Arabic; Dutch; Danish; English; French; Finnish; German; Italian; Japanese; Norwegian; Polish; Portuguese; Russian; Spanish; Swedish; Simplified Chinese; Turkish; Traditional Chinese
Regulatory approvals CE; FCC, Class A; RoHS; CB; EAC; EMF; ETL

Included Accessories

Accessories Cleaning cloth (×1); HDMI Cable (3 m) (×1); IR sensor cable (1.8 m) (×1); Philips logo (×1); Quick start guide (×1); Remote control and AAA batteries; RS232 daisy chain cable (×1); Touch Pen (×2); USB A to B cable (3 m) (×1); RS232 cable; AC Power Cord; Cable clip (×3); AC switch cover and Screw(×1); DVI-D cable; USB cover and screws
