Panasonic PT-MZ14KLWEJ Projector
£13443 (£16131.60 inc. VAT)
Availability: Please Call
Availability: Please Call
Panasonic PT-MZ14KLWEJ Key Features
- LCD Display Technology
- 14,000 Lumens
- 11 Optional Lenses (Click Here)
- WUXGA 1920*1200 Native Resolution
- 20,000 hour lamp life (typical)
- 3,000,000:1 Contrast Ratio
- 22.5kg (49.6lb.)
- Finished in White
- Supports 21:9 input signals
- Supports Art-Net DMX, PJLink™, Crestron Connected™ V2, Crestron XiO Cloud™, Extron XTP® and IPv61
- Compatible with Multiple PJ Firmware Batch Update Tool
- Scheduling function
- Presentation support system
- Free 360-degree installation
- Multi-unit Brightness and Colour Control function
- Multi-Screen Support System
- Waveform monitoring function
- 360° Installation
- Native Widescreen
- Lens Shift
- Curved Surface Projection
- Direct Power On
- Horizontal & Vertical Keystone Correction
- Portrait Mode
- HDBaseT
- Interchangeable Lens System
- Can Be Installed Vertically
- Lens-centred Design
- PIN Code Security
- Quick Power On
- Quick Power Off
- Warrantied for 24/7 use
- DICOM Simulation Mode
- Network Control
Panasonic PT-MZ14KLWEJ Downloads
- Exhibitions and large venues
- Horizontal Surface Projection
- Lecture Theatres
- LED/Laser
- Medical Imaging
- Museums
- Portrait Mode Applications
- Super bright applications
Panasonic PT-MZ14KLWEJ Specifications
| Categories | Conference / Large Venue HDBaseT Interchangeable Lens LED/Laser HD |
| Manufacturer | Panasonic (Click for rest of range) |
Panasonic PT-MZ14KLWEJ Optical Features |
|
| System | 3×25.4mm (1.0 in) diagonal |
| Resolution | WUXGA (1920*1200) |
| Aspect Ratio | 16:10 |
| Lumens | 14,000 |
| Contrast | 3,000,000:1 |
| Lamp | Multi-Laser Drive En |
| Lamp Life | 20,000hrs. |
| Lens | Lens Dependent |
| Interchangeable | Yes |
| Image Size | 30"-300" diagonal |
| Lens Shift | No |
Panasonic PT-MZ14KLWEJ Compatibility |
|
| Computer Resolutions | UHD, FHD, WUXGA, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac |
| Video Resolutions | 4K, UHD, HD, 720p, PAL, SECAM, NTSC |
Panasonic PT-MZ14KLWEJ Terminals |
|
| HDMI | 2 |
| RGBHV (15-pin HD) | 1 |
| HD-SDI | 1 |
| USB | 2 |
| RS-232 | 3 |
| HDBaseT | 1 |
| Network Ready | Yes |
Panasonic PT-MZ14KLWEJ General |
|
| Speakers | No |
| Remote Control | Panasonic PT-MZ14KLWEJ only |
| Noise | 35db (30db ECO mode) |
| Dimensions | 650*185*440mm (W*H*D) |
| Weight | 22.50kg |
| Power Supply | AC 100-240 V, 50/60 Hz |
| Power Consumption | 540Watts |
| Manufacturers Warranty | 3 Year/20,000 Hours (Whichever first) |
| Light Source Warranty | 3 Year/20,000 Hours (Whichever first) |
Additional Specs |
|
| Connectivity Details | BNC × 1: 3G/HD-SDI input HDMI 19-pin × 2 (Compatible with HDCP 2.3, Deep Color, 4K/60p signal input5), CEC supported D-sub 9-pin (female) × 1 for external control (RS-232C compliant) D-sub 9-pin (male) × 1 for link control (RS-232C compliant) D-sub 9-pin (female) × 1 for external control (parallel) M3 × 1 for wired remote control M3 × 1 for link control (for wired remote control) RJ-45 × 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT compliant), 100Base-TX (Compatible with PJLink [Class 2], Art-Net, HDCP 2.3, Deep Color, 4K/60p signal input*5 ) RJ-45 × 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink [Class 2], Art-Net) USB connector (Type A) × 1 for power supply (Output: 5 V / 2 A) USB connector (Type A) × 1 for optional AJ-WM50 Series Wireless Module, for USB memory |
| Keystone Correction | Vertical: ±45 ° (±5 ° with ET-EMU100, ±14 ° with ET-EMW200/ET-EMW300, ±22 ° with ET-EMW400/ET-EMW500) Horizontal: ±40 ° (±0 ° with ET-EMU100, ±8 ° with ET-EMW200/ET-EMW300, ±15 ° with ET-EMW400/ET-EMW500). When Vertical and Horizontal Keystone are used simultaneously, correction cannot be made exceeding a total of 55 °. |
| Applicable Software | Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Geometry Manager Pro, Projector Network Setup Software, Smart Projector Control for iOS/Android |
Ivojo Multimedia are approved Panasonic dealers and supply only UK products with full UK warranties.
Panasonic PT-MZ14KLWEJ Optional Lenses
| Description | Price | Inc. VAT |
| Panasonic ET-EMU100 Ultra Short Throw Fixed Lens | £11266 | £13519.20 |
| Panasonic ET-EMW200 Wide Zoom Lens | £3685 | £4422.00 |
| Panasonic ET-EMW300 Short Throw Zoom Lens | £4604 | £5524.80 |
| Panasonic ET-EMW400 Short Throw Zoom Lens | £4604 | £5524.80 |
| Panasonic ET-EMW500 Semi-Short Throw Zoom Lens | £4603 | £5523.60 |
| Panasonic ET-EMS600 Standard Throw Zoom Lens | POA | |
| Panasonic ET-EMS650 Standard Zoom Lens | £1773 | £2127.60 |
| Panasonic ET-EMT750 Semi-Long Throw Zoom Lens | £3512 | £4214.40 |
| Panasonic ET-EMT700 Semi-Long Throw Zoom Lens | POA | |
| Panasonic ET-EMT800 Semi-Long Throw Zoom Lens | POA | |
| Panasonic ET-EMT850 Long Throw Zoom Lens | £3512 | £4214.40 |
Panasonic PT-MZ14KLWEJ Accessories
| Description | Price | Inc. VAT |
| Seddon Flight Case 25 Hard case for projectors weighing 10-25kg | £167.00 | £200.40 |
Panasonic PT-MZ14KLWEJ Alternatives
| Product | Type | ANSI Lumens | Weight | Price | Inc. VAT |
| Epson EB-PU2113W | LCD | 13000 | 23.7 | £10567 | £12680.40 |
| Epson EB-PU2213B | LCD | 13000 | 23.7 | £11365 | £13638.00 |
| Panasonic PT-MZ14KLBEJ | LCD | 14000 | 22.5 | £13295 | £15954.00 |
