Epson EB-L1715S Projector &
Epson ELPLL08 Projector Lens
Epson EB-L1715S
- 15000 ANSI Lumens
- SXGA+ 1400*1050 Native Resolution
- 2500000:1 Contrast Ratio
- 20000 hour lamp life (typical)
- Lens Shift function
- 23.7kg (52.2lb.)
- 5 year/20,000 hours (whichever first) RTB warranty
- Epson EB-L1715S
Epson EB-L1715S & Epson ELPLL08
Epson ELPLL08 Lens Only
£2145 (£2574.00 inc. VAT)
Availability: In stock
Availability: In stock
Select a Screen |
Min. Throw | Max Throw | Foot Lamberts |
|
10.86m | 15.30m | 464.40 |
Screen Size Table (Figures in metres)
Width | Height | Diagonal | Min. Throw | Max Throw | Area | Foot Lamberts* |
0.50 | 0.38 | 0.62 | 2.71 | 3.83 | 0.19 sq.m. | 7432.24 |
1.00 | 0.75 | 1.25 | 5.43 | 7.65 | 0.75 sq.m. | 1858.06 |
1.50 | 1.12 | 1.88 | 8.14 | 11.48 | 1.69 sq.m. | 825.80 |
2.00 | 1.50 | 2.50 | 10.86 | 15.30 | 3.00 sq.m. | 464.52 |
2.50 | 1.88 | 3.12 | 13.57 | 19.12 | 4.69 sq.m. | 297.29 |
3.00 | 2.25 | 3.75 | 16.29 | 22.95 | 6.75 sq.m. | 206.45 |
4.00 | 3.00 | 5.00 | 21.72 | 30.60 | 12.00 sq.m. | 116.13 |
5.00 | 3.75 | 6.25 | 27.15 | 38.25 | 18.75 sq.m. | 74.32 |
*Foot lamberts are a measure of the brightness of the final image. Multiply the figure in the foot lamberts column by the gain of your screen to obtain a true figure.
Throw Distance Table (Figures in metres)
Distance | Minimum Width | Maximum Width |
1 | 0.13 | 0.18 |
2 | 0.26 | 0.37 |
3 | 0.39 | 0.55 |
4 | 0.52 | 0.74 |
5 | 0.65 | 0.92 |
6 | 0.78 | 1.10 |
7 | 0.92 | 1.29 |
8 | 1.05 | 1.47 |
Please note that these tables are based on figures supplied by the manufacturer and Ivojo cannot vouch for their accuracy. If in doubt please call us.
