AV Stumpfl VarioClip Clamp Rear Projection BCC-RW752/R10 Projector Screen

AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image. Click to enlarge.
AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image AV Stumpfl BCC-RW752/R10 340" (8.63m) 16:10 aspect ratio projection screen product image

Key Features

  • Variable size through plug-in modules
  • QuikClip technology means no studs or press snaps
  • Torx screw locking mechanism for maximum strength
  • Adjustable surface tension
  • 5 year warranty
  • Custom sizes available
Type: Folding
Diagonal: 340" (8.63m)
Aspect Ratio: 16:10 (1.6:1)
Viewable Area: 24' 0" x 15' 11" (732.0 x 457.0cm)
Finish: AV Stumpfl Flex Rear CI
£9397 (£11276.40 inc. VAT)
Availability: 7-10 Days

AV Stumpfl BCC-RW752/R10

Select A Projector to view throw distance from the AV Stumpfl BCC-RW752/R10
Projector Min. Throw Max Throw Foot Lamberts
Please note that throw figures can vary within manufacturing tolerances

AV Stumpfl BCC-RW752/R10 Specifications

Viewable Screen Dimensions

 Metric Imperial
Width 7320mm 288.2"
Height 4570mm 179.9"
Diagonal 8629mm 339.7"
Area 33.45m² 360.08'

Overall Material Surface Dimensions
Width 7520mm 296.1"
Height 4770mm 187.8"
Diagonal 8905mm 350.6"
Top Border Size 100mm 3.94"
Bottom Border 100mm 3.94"
Left & Right Border Size 100mm 3.94"
Area 35.87m² 386.11'

Surface Specifications
Surface Finish AV Stumpfl Flex Rear CI
Gain 1.18
Viewing Angle 90°
Foot Lamberts / ANSI Lumen 3.28 / 1000
cd/m2 (nits) / ANSI Lumen 11.23 / 1000

Additional Information

Weight 73.00kg.
Suggested Max. Viewing Distance 18.3m for fine detail
27.4m for text (spreadsheets etc.)
36.6m for video and images

AV Stumpfl Flex Rear CI Projection Surface

PVC vinyl greyish translucent surface. Vivid colour reproduction and designed for resolutions up to 8K+. Flexible and foldable, flame retardent and non-aging. Clean with water. Seamless up to 2.1m.
AV Stumpfl Flex Rear CI Gain Chart

AV Stumpfl Monoblox/Vario/VarioClip 32 Accessories

ProductDescriptionPriceInc. VAT
AV Stumpfl BFZ-CASE/G/G Large grey flight case for Stumpfl Monoblox and Vario 134×38×37cm £514 £616.80
