Vogels FVW3347
3×3 ;Video Wall Floor Stand
40 to 47" / Max 80kg per display
Vogels FVW3347 (7922470)
Would you like to place your 2x2 video wall in a free standing environment? Vogel's has put together a complete kit for a professional floor stand solution. This video wall floor stand kit is suitable for 55inch (1397 mm) LCD displays with a maximum weight of 80kg (176 lb)/display. This modular system is quick and easy to install. Combine the floor stand base and crossbar with the PUC29 poles, display interface plates and display interface strips to create your perfect video wall. With the specially designed (3D) interface strips, you can easily align any screen on the X, Y and Z axis. Even after installation, the screens remain easily accessible for maintenance purposes.
Precision with ease for a seamless installation
When you are unable to install your 2x2 video wall on the wall, Vogel's offers the solution to mount your video wall using a floor stand solution. This is possible with the modular Connect-it system. Combine the floor stand base and crossbar with Connect-it PUC 29 poles, one or more display interface plates and display interface strips to create a perfect and seamless video wall.
With ease of installation in mind, Vogel's has designed a unique, adjustable floor stand. This floor stand makes it possible to install a PUC 29 pole perfectly vertically. This floor stand also has adjustable feet that make it possible to position your floor stand perfectly horizontal. How easy is that?
The display interface strips used when mounting video walls have maximum adjustability and can be adjusted in three directions (3D). These 3D display interface strips can be used to create an absolutely perfect and seamless video wall.
Smart design makes maintenance simple
The built-in service position makes it possible to connect cables after installation of the displays. Each individual display can also be removed for maintenance or replacement. The built-in locking function prevents any horizontal movement of the displays. This video wall floor stand kit is suitable for LCD displays of 55 inch (1397 mm) with a maximum weight of 80 kg (176 lb)/display.
Install your video wall quickly and easily. Choose precision with ease for a seamless end result. A solution that suits you and your customers perfectly and can be installed in any environment. An attractive design, one system for a variety of applications, easy to maintain, and both durable and versatile
- Max Load: 80.00kg.
- Order Code: 7922470
- See entire Vogels Video Wall Hardware Range
- Conferences
- Digital Signage
- Exhibitions
- Museums and Art Galleries
- Places of Worship
- Public Display
- Retail
- Scheduling Display
- Video Walls
Availability: 3-5 days
Vogels FVW3347 Specifications
| Product group | Floor stand module |
| Series | Connect-it |
| Guarantee | 5 years |
| Colour | Black |
| Video wall configuration | 2 × 2 |
| Suitable for screen type | |
| LCD |
| Height | 2091mm |
| Min. screen size | 40 inch |
| Max. screen size | 47 inch |
| Max. weight load | 80kg |
| Pole length | 2000 mm |
| Overall Height | 2084mm |
FVW3347 Component Parts
| Product Code | Description |
| 1 × Vogels PFA9129 | 115㎝ Video Wall Cross Bar |
| 1 × Vogels PFF7920 | Video wall floor stand base finished in Black |
| 1 × Vogels PFS3504 | Vertical mounting arms for LCD/LED monitors and commercial TV's (Max. 160kg; -3/+7°Tilt; VESA 100-400mm) |
| 1 × Vogels PUC2920 | 200㎝ Connect-it Video Wall column finished in black |
