NEC MultiSync M981 LED Large Format Display Monitor

NEC MultiSync M981 98 inch Large Format Display product image. Click to enlarge.

NEC MultiSync M981 98 inch Large Format Display product image

NEC MultiSync M981 98 inch Large Format Display Front View product image

£6150 (£7380.00 inc. VAT)
Availability: In stock

NEC MultiSync M981 Suggested Applications

Hospitality

Public Display

Classrooms & Training Rooms

Video conferencing

Exhibitions

Museums and Art Galleries

Key Features

98" Diagonal IPS with Direct LED backlights Panel
Unhindered readability - no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
Enhanced imaging performance - advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
Mission-critical 24/7 ready operation - the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
Future Ready Connectivity - featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
Secure remote management - control your devices remotely and securely using NEC NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources
VESA 600×400; M8 mounting points
USB Media Player - Play JPeG images, MP3 audio or MPG video from a USB memory stick
DICOM Support - For accurate medical imaging
Landscape/Portrait Mode - The MultiSync M981 can be installed in either standard landscape or portrait orientation
OPS Slot - Allows expansion modules such as PC boards, HD-SDI interfaces to be added
LAN Control/Monitoring - The monitor can be controlled through your local area network
Designed for 18/7 use - Warranty covers use up to 18 hours per day

Intuitive professional content delivery

Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation and high haze panel to reduce reflections when ambient light is high, the M series is the professional way to deliver your message, yet at an attractive price point.

With the optional NEC MediaPlayer or the more powerful Intel Smart Display Module (Intel SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment and meeting room applications, the M Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.

NEC MultiSync M981 Downloads

Brochure

Instruction Manual

Mounting Options & Accessories

Unicol PLX3

Unicol PZX9

Unicol TCAVT

Unicol PLA4

Unicol FCS4

Unicol RTM7

Unicol FCGDH

Unicol FCGSH

Unicol AVMW91

NEC MultiSync M981 Summary
Manufacturers Part No.	60005069
Model	NEC MultiSync M981
EAN / UPC	5028695125919
Display Type	IPS with Direct LED backlights
Features	USB Media Player DICOM Support Landscape/Portrait Mode OPS Slot LAN Control/Monitoring Designed for 18/7 use
Diagonal	98"
Native Resolution	3840×2160
Brightness	500cd/m²
Contrast	8,000:1
Colours	1.073 Billion (10bit)
Horizontal Frequency	60KHz
Vertical Frequency	23 - 76Hz
Connectivity
HDMI	2
DisplayPort	2
USB	3
RS-232	1
General Specifications
Speakers	Integrated Audio Amplifier (for optional
Warranty	3 years warranty incl. backlight; optional 4. + 5. year warranty extension
Monitor Dimensions	219.5 × 125 × 8.4cm (w×h×d)
Weight	67kg.
VESA	600×400; M8
Power Supply	100-240 V AC; 50/60 Hz; internal
Consumption	340w
Connectivity Details
Digital Video Inputs	2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP)
Digital Audio Inputs	1 x DisplayPort; 2 x HDMI
Control Inputs	LAN 100Mbit; remote control wire (3,5mm jack); RS232
Control Output	1 x LAN 100Mbit
Data Inputs	1 x USB 2.0 (Downstream); 1 x USB 2.0 (Powered 5V/2A, Firmware Updates); 1 x USB 2.0 Type-B (Downstream)
Digital Video Output	1 x DisplayPort (loop through: DisplayPort, SDM slot-in PC)
	1 x HDMI (loop through: HDMI, SDM slot-in PC)
	DP (in) to HDMI (out) conversion
Analogue Audio Output	1 x 3,5 mm jack
Input Detection Seq	Custom
	First
	Last
Intel SDM	accepts Intel® Smart Display Modules Large and Small up to 66 W
Computer Module Slot	RPi Compute Module 4
External Control	AMX NetLinx Support; ASCII Control Commands; Crestron Connected; HDMI CEC; HTTP Browser; PJLink; Scheduled Timer; SNMP
Remote Management	Automated Email Alerts; NEC NaViSet Administrator 2
Other Features
Special Features	DICOM Simulation; HDMI ARC; Powered USB Port (10 W); Removable Logo
Temperature Sensor	Integrated, 3 sensors, triggered actions programmable
Bezel Width	14.3 (left, right and top); 14.8 (bottom)mm
Package Dimensions	2,350 × 1,400 × 310(mm)
Package Weight	98.7(kg)
Ingress Protection	IP5x (front); IP2x (back)
Orientation	Landscape; Portrait
Operating Temperature	+0 to +40°c
Operating Humidity	20 to 80%
Storage Temperature	-20 to 60°c
Storage Humidity	10 to 80%
Power Saving Mode	< 0.5; < 2 (Networked Standby) Watts
Energy Efficiency	Energy consumption: 205 kWh/1000 h; Energy efficiency class: F; LED backlight
Ecological Standards	EnergyStar 8.0
Safety & Ergonomics	BSMI; CE; EAC; EMC Class B; Energy Star 8; FCC Class B; KC/KCC; PSB; RCM; RoHS; VCCI
Operating Hours	24/7
Security	Disable HW Buttons; Disable IR Functionality; Emergency Notification
Fire Resistance	Metal backcover, plastic material certified acc. to UL94-5VB
Included Accessories
Accessories	2 × AAA batteries; Display; HDMI Cable; Power Cable; Remote Control; Setup Manual
