Chief SL236SPI

Projector Lift for installation class projectors
Projector dimensions up to 521*235*578mm and 15.9kg

£3091 (£3709.20 inc. VAT)
Availability: Please Call

Chief SL236SPI Description

The SL236 provides Extended Travel with exceptionally smooth and quiet movement and is a great option for suspended ceilings in homes and corporate offices.

Chief SL236SPI Key Features

• Requires SLB bracket (please call)
• Two internal outlets
• Fits most installation requirements, needing only 11" of clearance above the ceiling
• Easily accommodates multiple control options
• Extended Downward Travel up to 36" with 3 stopping positions
• For fixed suspended installations
• Not suitable for ultra short throw projectors

Chief SL236SPI Specifications

Adjustments	Roll: 2°
Pitch	15°
Yaw	10°
Ceiling Closure	23.9" x 23.9" ( 607 x 607 mm)
Ceiling Opening	25.5" x 28.5" x 11.1" (648 x 724 x 282 mm)
Certifications	CE Approved, FCC Approved, T&
Colour	White
Extension	36.0"
Max Equip Size (H X W X D)	9.3" x 20.5" x 22.8" (235 x 521 x 578 mm)
Overall Dimensions (H X W X D)	25.1" x 28.3" x 12.3" (638 x 719 x 311 mm)
Power Requirements	230 VAC, 50 Hz, 0.75 A
Shipping Weight	123.00 lbs
Weight Capacity	35 lbs (15.9 kg)
